6.4 PNO CLASS 2 16 bits
Data exchange
DDLM_Data_Exchange
Input word IWx
Byte
1
2
Bit
15 – 8
7 – 0
Data
2
15
– 2
8
2
7
– 2
0
Data_Exchange – Position data
Format for preset adjustment value (description of the function see page 107)
Output word OWx
Byte
1
2
Bit
15
14 – 8
7 – 0
Data
0 / 1
2
14
– 2
8
2
7
– 2
0
Preset execution
Preset adjustment value
Configuration data
see note on page 89
Device Class 2: 0xF0 (1 word input data for position value, consistent /
1 word output data for preset adjustment, consistent)
DDLM_Chk_Cfg
Byte
1
Bit
7
6
5 – 4
3 – 0
Data
1
1
11
0
F
0
Consistency
Word format
Input data
Length code
