6.9.6 Scaling function
Defines whether the position is scaled according to the parameters
- "Steps per revolution"
- "Total measuring range"
If Class 2 is switched off, the position value cannot be scaled or adjusted.
6.9.7 Scaling parameter PNO CLASS 2
If the scaling parameters are activated with the Scaling function, the physical
resolution of the measuring system can be changed. The position value output is
binary decoded and is calculated with a zero point correction and the count direction
set. The measuring system does not support decimal numbers in this configuration or
numbers of revolutions (gearbox function) deviating from exponents of 2.
6.9.7.1 Steps per revolution
Defines how many steps the measuring system outputs for one revolution of the
measuring system shaft.
8192 steps per revolution (Max. value see nameplate)
6.9.7.2 Total measuring range
Defines the total number of steps of the measuring system before the measuring
system restarts at zero.
upper limit PNO CLASS 2 16 bit
upper limit PNO CLASS 2 32 bit
The actual upper limit for the measurement length to be entered in steps is dependent
on the measuring system version and can be calculated with the formula below. As
the value "0" is already counted as a step, the end value = measurement length in
steps - 1.
Total measuring range = Steps per revolution * Number of revolutions
To calculate, the parameters steps/rev. and the number of revolutions can be read
on the measuring system nameplate.
