Printed in the Federal Republic of Germany TR-Electronic GmbH 2007, All Rights Reserved
02/23/2017 TR - ECE - BA - DGB - 0060 - 05 Page 119 of 131
6.10 Configuration example, SIMATIC
Manager V5.3
For the configuration example, it is assumed that the hardware configuration has
already taken place. The CPU315-2 DP with integrated PROFIBUS-interface is used
as CPU.
File names and entries in the following masks are to be regarded only as
examples of the procedure.
For the GSD file to be transferred to the catalogue, it must first be installed:
