TR-Electronic CES-65 - Overview

Parameterization and configuration
 TR-Electronic GmbH 2007, All Rights Reserved Printed in the Federal Republic of Germany
Page 90 of 131 TR - ECE - BA - DGB - 0060 - 05 02/23/2017
6.1 Overview
Configuration
Operating parameters
*· Length
Features
PNO Class 1
Page 91
- Count direction
16 bit IN
- No measuring system scaling, the measuring
system has the base resolution according to the
nameplate
- 16 byte diagnosis data
- Count direction
PNO Class 1
Page 92
- Count direction
32 bit IN
PNO Class 2
Page 93
- Count direction
- Class 2 on/off
- Commissioning diagnostics
- Scaling function
- Steps per revolution
- Total measuring range
16 bit IN
16 bit OUT
- Measuring system scaling is possible, however
the number of steps / revolution must be an
integer and the number of revolutions an
exponent of 2
- Preset adjustment via the bus
- Count direction
PNO Class 2
Page 95
- Count direction
- Class 2 on/off
- Commissioning diagnostics
- Scaling function
- Steps per revolution
- Total measuring range
32 bit IN
32 bit OUT
TR-Mode,
Position
Page 97
- Count direction
- Commissioning diagnostics
- Short Diagnostics
- Total measuring range
- Revolutions numerator
- Revolutions denominator
- Code SSI-Interface
- Data bits SSI-Interface
- Code PROFIBUS-Interface
- Preset
- Limit switch
32 bit IN
32 bit OUT
- Measuring system scaling possible, the number
of steps per revolution can be a decimal number
and the number of revolutions any number (not a
exponent of 2).
- Preset adjustment via the bus
- Count direction
- Configuration of the SSI interface
- Output code programming
- Preselection of the values for the external Preset
inputs
- Limit switch
TR-Mode,
- Position +
- Velocity
Page 102
- Count direction
- Commissioning diagnostics
- Short Diagnostics
- Total measuring range
- Revolutions numerator
- Revolutions denominator
- Code SSI-Interface
- Data bits SSI-Interface
- Code PROFIBUS-Interface
- Preset
- Limit switch
- Velocity
32 bit IN
16 bit IN
32 bit OUT
- Measuring system scaling possible, the number
of steps per revolution can be a decimal number
and the number of revolutions any number (not a
exponent of 2).
- Preset adjustment via the bus
- Count direction
- Configuration of the SSI interface
- Output code programming
- Preselection of the values for the external Preset
inputs
- Limit switch
- Velocity output
* from the bus master perspective
