Parameterization and configuration
 TR-Electronic GmbH 2007, All Rights Reserved Printed in the Federal Republic of Germany
Page 118 of 131 TR - ECE - BA - DGB - 0060 - 05 02/23/2017
6.9.12 Lower limit switch / Upper limit switch
Availability
PNO CLASS1 16 + 32
PNO CLASS2 16 + 32
TR-Mode Position
X
TR-Mode Position + Rpm.
X
not supported!
not supported!
page 97
page 102
If the status switched on (see Teach-In function page 109) the measuring system can
inform the master via a bit whether the actual value is within the limits.
Limit switch bit = 0
actual value  lower limit or actual value  upper limit
Limit switch bit = 1
actual value < lower limit or actual value > upper limit
lower limit
0
upper limit
programmed total measuring length in increments – 1,
within  33 554 432
default
Lower limit switch = 0, Upper limit switch = 4096
6.9.13 Data bits SSI-Interface
Availability
PNO CLASS1 16 + 32
PNO CLASS2 16 + 32
TR-Mode Position
X
TR-Mode Position + Rpm.
X
not supported!
not supported!
page 97
page 102
Defines the number of data bits on the SSI interface.
Output format: MSB left-justified
lower limit
8
upper limit
32
default
24
6.9.14 Velocity [1/x rpm]
Availability
PNO CLASS1 16 + 32
PNO CLASS2 16 + 32
TR-Mode Position
TR-Mode Position + Rpm.
X
not supported!
not supported!
not supported!
page 102
With this parameter, the specified rotational speed can be scaled in arbitrary steps
between 1/1 and 1/100 revs./min.
