Trace Engineering RC7 User Manual

ã 1999 Trace Engineering
RC7 & RC7GS Remote Controls
6
3. Inverter LED
The green Inverter LED indicates the inverter is switched ON and ready to
provide backup power. If there is no ac power, the inverter LED will be ON solid,
indicating that the inverter/charger is in the inverter (ON) mode.
Inverter LED Other LEDs or Devices Meaning
ON (solid) Inverter ON
Flashing Charge LED (flashing) Inverter ready (charging)
Slow Flash Load Sense Searching
Flashing Error LED ON + Buzzer Inverter Error
OFF Inverter Switched OFF
4. Charge LED
The Charge LED indicates the current battery charge mode.
Charge LED Other LEDs or Devices Meaning
ON (solid) Bulk Charging
Slow Flash Absorption Charging
Fast Flash Batt. Full LED ON Float Charging
Very Fast Flash Equalize Charging
OFF Inverter Mode (no charging)
5. Batt. Full LED
The Batt. Full LED indicates the state of charge on the batteries. This LED
will not illuminate until the batteries have charged up to at least 90%. The
duration of the LED’s ON time will increase until the batteries reach 100%, which
at that time, the LED will be ON solid. In the inverter mode, the OFF time
duration of the LED will increase until the batteries discharge to below 90% at
which time the LED will extinguish.
Batt. Full LED Other LEDs or Devices Meaning
Solid Battery Fully Charged (100%)
Flashing Battery Charged 90% or
higher
OFF Battery Below 90% Charge
6. Error LED
The Error LED indicates that there is a problem with the inverter/charger or
batteries. Check the LCD display to find and correct the nature of the problem.
Error Other LEDs or Devices Meaning
ON (solid) Check System
3.0 OPERATION

Trace Engineering RC7 Specifications

General

Brand	Trace Engineering
Model	RC7
Category	Remote Control
Language	English
