Trace Engineering RC7 User Manual

ã 1999 Trace Engineering
RC7 & RC7GS Remote Controls
Figure 28
Generator Start/Stop (on User Menu)
4. Generator Stop
The RC7GS can be configured to shut down the generator automatically
when the batteries reach 90 to 99% SOC, or when the charger initiates the
Absorption or the Float mode of charging. Refer to the inverter/charger’s
Operator’s manual for a detailed description on charging modes. The default is
Manual (Push Off).
Figure 29
Generator Start/Stop (on User Menu)
The generator can be stopped at any time by accessing the user menu until
the “Gen Start/Stop: Press (On/Off)” menu is displayed. Press the ON/Off push-
button on the RC7GS front panel until the generator stops.
NOTE: The generator will start immediately if the auto-start parameters are still
met.
3.0 OPERATION
Generator Stop:
Manual (Push OFF)
Generator Stop:
Auto at 90% SOC
Generator Stop:
Auto at 95% SOC
Generator Stop:
Auto at 99% SOC
Generator Stop:
Auto at Absorb
Generator Stop:
Auto at Float
The generator can be started or stopped at any time by pressing the DOWN
arrow push-button (User Menu) until the Gen Start/Stop menu is displayed.
Press and hold the On/Off push-button on the RC7GS front panel until the
generator starts or stops. Release the push-button as soon as the generator
starts. If the inverter/charger senses an ac supply while the remote control
On/Off push-button is pressed, it will shut down the generator.
NOTE: If the genset is manually started from the remote, a manual override is
initiated and the generator will NOT stop automatically. Shut down the generator
manually.
Figure 27
Generator Start/Stop (on User Menu)
Gen Start / Stop:
Press (ON / OFF)
822-4A-004
On / Off
Gen Start / Stop:
Press (ON / OFF)
822-4A-004
On / Off
16
