Trace Engineering RC7 User Manual

ã 1999 Trace Engineering
RC7 & RC7GS Remote Controls
System Status:
Waiting for AC
RC7 and RC7GS Users Menu
System Status:
AC Available
System Status:
Searching
System Status:
Inverting
System Status:
Bulk Charging
System Status:
Absorption Chrg
System Status:
Float Charging
System Status:
Equalizing
System Status:
Hi Bat / Stop Chrg
System Status:
Lo Bat / Start Chrg
System Status:
DCLD Lockout Err
System Status:
Charger Fault
Genset Status:
Pending Genstart
Genset Status:
Cranking Genset
Genset Status:
Man Stop Only!!
Genset Status:
Gen wont Start
Genset Status:
Low AC Input V
Genset Status:
Starter Cooldown
Genset Status:
Gen Quiet Fault
RC7GS only
Avg Shunt Amps:
+ / - 0 Amps DC
FET Temp:
000 Counts
Est. Bat. Cap:
xx Amp-hrs (x 8)
System Status Display Meters Display
AC Source Inverter Mode Charger Mode Error Mode
System Status:
Otemp / Less Load
System Status:
Overload
Battery:
00.0 Volts DC
Inv / Chg Current:
+ / - 0 Amps DC
AC Input:
0 Amps AC
Inverter Output:
VAC 0
Battery Temp:
000 Counts
Xformer Temp:
000 Counts
Batt State of Charge:
xx% Full
Batt State of Charge:
E [] [] [] [] [] [] [] [] [] F
Time Left to Run:
x.x Hours
Time Left to Charge:
x.x Hours
Set Shore Power:
x.x Amps
Gen Start / Stop:
Press (ON / OFF)
System Status Messages
3.0 OPERATION
37

Trace Engineering RC7 Specifications

General

Brand	Trace Engineering
Model	RC7
Category	Remote Control
Language	English
