Trace Engineering RC7 User Manual

ã 1999 Trace Engineering
RC7 & RC7GS Remote Controls
RC7 and RC7GS Setup Menu
The Setup menu configures the RC7 and RC7GS to specific operating
system parameters. To access the Setup menu press and hold the UP and
DOWN arrows push-buttons for approximately 5 seconds until the LCD display
clears. Choose the desired configuration settings for the system from the
appropriate menu. Exit the Setup Menu by pressing both the UP and Down
arrow push-buttons for approximately 5 seconds. The new settings will be saved
in nonvolatile memory 20 seconds after exiting the Setup mode (if nothing is
changed during the waiting period).
The initial menu that will appear in the LCD display is the Search Sense
menu shown below.
Search Sense:
Defeat
Figure 12
Initial LCD Display Item
The following menu items appear in the exact sequence they appear on the
RC7. Refer to pages 36-37 for the complete menu structure.
1. Search Sense
Search Sense enables or disables the power-saving “search” mode logic
circuitry. Refer to the inverter’s Operator’s manual for a complete description of
the Search Sense mode.
To configure the Search Sense mode, use the RIGHT arrow push-button
(Settings), to scroll to the desired setting. The default setting is Defeat .
Defeat disables the Search Sense function. The remaining selections,
specify the minimum wattage load that must be present on the inverter to qualify
as a load and bring the inverter out of the search mode. After selecting, press
the DOWN arrow to access the next menu.
Figure 13
Search Menu Selections
3.0 OPERATION
9
Search Sense:
Defeat
Search Sense:
About 5W load
Search Sense:
...10W load
Search Sense:
...40W load
Search Sense:
> 40W load
••••
