RC7 & RC7GS Remote Controls
2. Select Genset
After setting the clock, press the UP arrow once to access the Select
Genset menu. Select the type and model of the generator by pressing the
Settings push-button (RIGHT arrow) until the genset’s name and model is
displayed in the LCD readout. The default is Onan QuietDiesel.
NOTE: Not all generators are supported.
CAUTION: Other 30 through Other 80 are reserved for future use and must not
be selected.
3. Generator Start
After setting the clock and selecting a generator, set the parameters for
automatically starting the genset based upon a battery voltage or State-of-
Charge (SOC). Press the UP arrow and scroll through the menus to access the
Generator Start menu. Press the Settings push-button (RIGHT arrow) until the
required setting is in the LCD display.
NOTE: The Auto Gen parameters can not set unless the clock is set-up first.
The default Generator Start selection is Manual (Push On). This setting
disables all automatic start functions. Any other selection from the Generator
Start menu, enables the RC7GS to automatically start the generator based upon
the battery’s state-of-charge.
Figure 25
Select Genset Display
Select Genset:
Onan QuietDiesel
Select Genset:
PowerTech 2-Wire
Select Genset:
PowerTech 3-Wire
Select Genset:
Other 80
••••••••
Figure 26
Generator Start Menu Selections
Generator Start:
Manual (Push ON)
Generator Start:
Auto at 40% SOC
Generator Start:
Auto at 60% SOC
Generator Start:
Auto at 11.0 VDC
Generator Start:
Auto at 12.2 VDC
••••
3.0 OPERATION
15
