RC7 & RC7GS Remote Controls
4. Battery Type
To ensure the batteries are receiving the proper charge voltage, the Battery
Type must be selected for the type of batteries used in the system: GEL Cell,
Liquid Lead Acid and AGM. The default setting is GEL Cell.
This voltage varies depending on the batteries used, as specified below.
BATTERY TYPE BULK V DC FLOAT V DC EQUALIZE V DC
GEL Cell 14.1 V dc 13.6 V dc Defeated
Liquid Led Acid 14.6 V dc 13.4 V dc 15.5 V dc
AGM 14.4 V dc 13.4 V dc 15.5 V dc
Figure 16
Battery Type Selections
Battery Type:
GEL Cell
Battery Type:
Liquid Lead Acid
Battery Type:
AGM
5. Charge Rate
The battery charger’s maximum output current can be specified using the
Charge Rate menu. The default is 100% of the maximum charge rate. Refer to
the inverter/charger Operator’s manual for specific system settings.
Figure 17
Charge Rate Selections
Charge Rate:
100% of max
Charge Rate:
90%
Charge Rate:
80%
Charge Rate:
20%
Charge Rate:
10%
••••
