16 CTV-SVU02A-EN
Alarms
You can use the Tracer AdaptiView display to view alarms and to reset them. Alarms are
communicated to the display immediately upon detection.
Viewing the Alarms Screen
Touch the Alarms button in the main menu area (Figure 1, p. 7) to view the Alarms screen. A table
of active alarms appears that is organized chronologically with the most recent at the top of the list,
as shown in Figure 6. This example shows the default view, which appears each time you return
to the screen.
Note: A page number appears in the lower right corner of the screen. If a screen contains more
than one page, up/down arrows also appear for viewing the other pages.
Figure 6. Alarms screen (default view)
1. Reset Alarms button
2. Number of alarms
3. Sortable columns—The example is sorted by date/time.
4. Page numbering
5. Alarms categories—The example shows active alarms.
2
4
5
1
3
