Equipment Settings
Feature Settings
Ta b l e 8 lists the settings that are available as buttons on the Feature Settings menu screen, along
with their corresponding setting options. The chiller configuration determines which of the settings
appear.
Chilled Water Reset
Ta b l e 9 lists the settings that are available as buttons on the Chilled Water Reset menu screen, along
with their corresponding setting options. The chiller configuration determines which of the settings
appear.
Table 8. Feature Settings menu screen: Buttons and available setting options
Feature Available setting options
External Chilled Water Setpoint
•Enable
• Disable
External Current Limit Setpoint
•Enable
• Disable
Ice Building
•Enable
• Disable
Hot Gas Bypass
•Enable
• Disable
Hot Gas Bypass Maximum Timer
•Enable
• Disable
Minimum Capacity Timer
•Enable
• Disable
Security
•Enable
• Disable
LCI-C Diagnostic Encoding
•Text
•Code
Ext Base Loading Setpoint
•Enable
• Disable
Check Oil Filter Diagnostic
•Enable
• Disable
Table 9. Chilled Water Reset menu screen: Buttons and available setting options
Buttons Available setting options
Chilled Water Reset Type
• Disable
•Return
• Outdoor Air
•Constant
Return Reset Ratio Valid numerical range appears on screen.
Return Start Reset Valid numerical range appears on screen.
Return Maximum Reset Valid numerical range appears on screen.
Outdoor Reset Ratio Valid numerical range appears on screen.
