Appendix: Data for CenTraVac chillers
Data Graph Data Points
This appendix contains:
• Data points used in the default data graphs, organized by graph
• Data points available to include in custom data graphs, organized by component
Data Points Used in Default Data Graphs
Chiller Overview 1
Chiller Overview 2
Approach Temperature
Graph data point Axis
Active Chilled Water Setpoint Left Y-axis
Active Hot Water Setpoint Left Y-axis
Evaporator Leaving Evaporator Temperature Left Y-axis
Evaporator Entering Water Temperature Left Y-axis
Condenser Leaving Water Temperature Left Y-axis
Condenser Entering Water Temperature Left Y-axis
Calculated Chiller Capacity Right Y-axis
Graph data point Axis
Average Line Current %RLA Left Y-axis
Frequency Hz Left Y-axis
Differential Oil Pressure Left Y-axis
Graph data point Axis
Evaporator Approach Temperature Left Y-axis
Condenser Approach Temperature Left Y-axis
Approximate Evaporator Water Flow Right Y-axis
Approximate Condenser Water Flow Right Y-axis
Average Line Current Right Y-axis
