Trane AdaptiView User Manual

42 CTV-SVU02A-EN
Equipment Settings
Manual Control Settings
Table 10, p. 42, lists the settings that are available as buttons on the Manual Control Settings menu
screen, along with their corresponding setting options. The chiller configuration determines which
of the settings appear.
Outdoor Start Reset Valid numerical range appears on screen.
Outdoor Maximum Reset Valid numerical range appears on screen.
Table 9. Chilled Water Reset menu screen: Buttons and available setting options (continued)
Buttons Available setting options
Table 10. Manual Control settings menu screen: Buttons, available setting options, and status points
Feature Current value
Available setting
options Status points
Chiller Control Signal Auto/Manual
Manual mode: Up/down
arrows for changing the
setpoint
•IGV1 Position
•IGV2 Position
• Average Line Current
• AFD Frequency
• Active Chilled Water Setpoint (Active Hot Water
Setpoint if in Heating mode)
• Evap Leaving Water Temp (Cond Leaving Water
Temp if in Heating mode)
Evaporator Pump Override On/Off
•Auto
•On
• Evaporator Pump Manual Override Time Remaining
• Evap Water Flow Switch Status
• Active Chilled Water Setpoint
• Evap Leaving Water Temp
Condenser Pump Override On/Off
•Auto
•On
• Condenser Pump Manual Override Time Remaining
• Cond Water flow Switch Status
• Active Hot Water Setpoint
• Cond Leaving Water Temp
Head Pressure Control Override Auto/Manual
Manual mode: Up/down
arrows for changing the
value
• Condenser Entering Water Temperature
• Condenser Leaving Water Temperature
• Condenser Refrigerant Pressure
• Average Line Current
• Condenser Water Flow
• Approximate Condenser Water Flow
• Evaporator Refrigerant Pressure
• Differential Refrigerant Pressure
Clear Energy Consumption XXXX kWh • Clear
Oil Pump Control On/Off
•Auto
•On
• Oil Pump Manual Override Time Remaining
• Oil Differential Pressure
• Oil Pump Discharge Pressure
• Oil Tank Pressure
Clear Restart Inhibit XX:XX min:sec
• Clear Motor Winding Temperature #1
Motor Winding Temperature #2
Motor Winding Temperature #3
