6 CTV-SVU02A-EN
Introduction
AC power
The Tracer AdaptiView display receives AC power through its power cable, which is connected to
the Tracer UC800 controller. The Tracer UC800 controller must be powered On.
Communication
A separate cable provides communication between the Tracer AdaptiView display and the Tracer
UC800 controller. Alarms are communicated immediately upon detection.
Touchscreen Guidelines
The touch screen registers the downward pressure of a touch. Light, quick, yet deliberate presses
are most effective. Touching with more pressure has no effect.
Recommended tools to use: finger, thumb, pencil eraser. Do not use a pen or pencil point, or any
other sharp or pointed object that might scratch the screen surface.
If you apply and hold pressure at more than one point, the touch screen registers only the first
touch. For example, if you press a finger on an area of the screen that is not touch sensitive,
pressing a sensitive area with another finger will not register.
Holding on to the screen with your hand can cause unintended navigation, such as from thumb or
palm pressure.
Reference Sources
Additional information on Gear-Driven CenTraVac chillers with AdaptiView control can be found in
these documents.
• Gear-Driven Centrifugal Water-Cooled Liquid Chillers with Tracer AdaptiView™ Control
Installation, Operation, and Maintenance Manual (CVGF-SVX03)
• Diagnostics Descriptions, Troubleshooting Tables, and Control Component Overview for
Water-Cooled CenTraVac™ Chillers with Tracer AdaptiView™ Control (CTV-SVD03)
• Tracer™ TU Service Tool Programming Guide for Water-Cooled CenTraVac™ Chillers with
Tracer AdaptiView™ Control (CTV-SVP02)
• Tracer™ TU Service Tool Getting Started Guide (TTU-SVN01)
