Appendix: Data for CenTraVac chillers
Compressor
Oil System
Graph data point Axis
Average Line Current Left Y-axis
Active Current Limit Setpoint Left Y-axis
AFD Frequency Left Y-axis
IGV 1 Position Left Y-axis
Chiller Control Signal Left Y-axis
Compressor Refrigerant Discharge Temperature Right Y-axis
Graph data point Axis
Oil Differential Pressure Left Y-axis
Oil Tank Pressure Left Y-axis
Oil Pump Discharge Pressure Left Y-axis
Oil Tank Temperature Right Y-axis
Outboard Bearing Temperature Right Y-axis
Inboard Bearing Temperature Right Y-axis
