Table 23 Manuel Override View
Description Radio 1 Radio 2 Monitor Value(s): Attribute ID
Expansion Valve
Control
(%)
Auto Manual
Expansion Valve Control Target
EXV Position (%)
EXV Position (steps)
Evaporator Liquid Level (inches)
Evaporator Pump
Control
Auto On Evap Water Flow Switch Status:
Chilled Water Pump Relay:
Evap Pump Override Time Remaining:
Condenser Pump
Control
Auto On Cond Water Flow Switch Status:
Condenser Water Pump Relay:
Cond Pump Override Time Remaining
Slide Valve Control
(Slide Valve Control
Duty Cycle)
Auto Manual
Rate*
integers
-100 to +100
Evaporator Leaving Water Temperature
Average Line Current (%RLA)
Note:
positive integers 1 to 100 imply
loading at that duty cycle(5 sec
period)
negative integers -1 to -100 imply
unloading at that absolute value
duty cycle
0 implies hold
Pumpdown Command
and
Pumpdown Status
Start
Available
Not Available
In Progress
Inhibited
Abort Evaporator Refrigerant Pressure
Restart Inhibit Timer Clear (Button) Time Remaining
Head Pressure Control
Override
0= Auto
1= Off
2= Minimum
3=Maximum
"Off State" Output Command
Output Voltage at Desired
Minimum Flow
Desired Minimum Flow
Output Voltage at Desired
Maximum Flow
Actuator Stroke Time
Damping Coefficient
Condenser Water Pump
Prestart Time
Leaving Condenser Water Temperature
Leaving Condenser Water Temperature
Condenser Water Pump Flow Status
Output Voltage Commanded
Flow Commanded
Time to Get to Commanded Position
