Installation Mechanical
Lifting Procedure
CAUTION
Equipment Damage!
Never use a forklift to move the unit. The skid is not designed to
support the unit at any one point and using a forklift to move the
equipment may cause unit damage. Always position the lifting
beam so that cables do not contact the unit. Failure to do so may
result in unit damage.
NOTE: If absolutely necessary, the chiller can be pushed or pulled across a
smooth surface if it is bolted to wood shipping mounts.
 WARNING
Shipping Mounts!
Do not use the threaded holes in the compressor to lift or assist in
lifting the unit. They are not intended for that purpose and could
create a dangerous situation. Do not remove the wood mounts
until the unit is in its final location. Removal of wood shipping
mounts prior to unit final locating could result in death or serious
injury or equipment damage.
1. When the unit is at its final location, remove the shipping bolts that
secure the unit to the wood base mounts.
2. Rig the unit properly and lift from above or jack the unit (alternate moving
method). Use the points shown on the rigging diagram that ships with
the unit as shown in Figure 6. Remove the base mounts.
3. Install clevis connectors in lifting holes provided on the unit. Attach lifting
chains or cables to clevis connectors as shown in Figure 6. Each cable
alone must be strong enough to lift the chiller.
