Trane RTHD

24 RTHD-SVX01D-EN
Installation Mechanical
Table 8 Center of Gravity (in (mm))
Unit Configuration* X Y Z
E3G3G3 30.8 63.81 37.62
(782.32) (1621) (956)
E3G2G1 30.8 63.55 38.70
(782.32) (1614) (983)
E3F2F3 27.64 63.46 38.33
(702.056 (1612) (974)
E3D2E2 25.9 60.05 40.5
(658) (1525) (1029)
D3G3G3 30.85 63.48 37.44
(784) (1612) (951)
D3G2G1 30.58 68.56 37.79
(777) (1741) (960)
D3F2F3 27.7 63.4 38.14
(704) (1610) (969)
D3D2E2 25.97 59.95 40.31
(660) (1523) (1024)
D2G3G3 30.85 63.48 37.44
(784) (1612) (951)
D2G2G1 30.58 68.56 37.79
(777) (1741) (960)
D2F2F3 27.7 63.4 38.14
(704) (1610) (969)
D2D2E2 25.97 59.95 40.31
(660) (1523) (1024)
D1G1G1 30.58 68.56 37.79
(777) 1741) (960)
D1G2G2 30.77 63.55 37.72
(782) (1614) (958)
D1F1F2 27.92 63.47 38.7
(709) (1612) (9833)
D1D1E1 25.91 60 40.47
(658) (1524) (1028)
C2F2F3 27.92 63.47 38.7
(709) (1612) (9833)
C2D3E3 26.13 59.74 40.08
(664) (1517) (1018)
C2D4E4 26.13 59.74 40.08
(664) (1517) (1018)
C1E1F1 26.36 63.49 40.95
(670) (1613) (1040)
C1D5E4 26.13 59.74 40.08
(664) (1517) (1018)
C1D6E5 26.13 59.74 40.08
(664) (1517) (1018)
B2C2D2 22.4 58.29 33.51
(569) (1481) (851)
B2B2B2 22.88 58.11 35.43
(581) (1476) (900)
B1C1D1 22.32 58.23 33.65
(567) (1479) (855)
B1B1B1 22.84 58.13 35.59
(580) (1477) (904)
Designator corresponds to digits 6, 7, 14, 15, 21, 22 of model number
