General Information
Installation Overview
For convenience, Table 2 summarizes responsibilities that are typically asso-
ciated with the RTHD chiller installation process.
Refer to the Installation Mechanical and Installation Electrical sections of this
manual for detailed installation instructions.
• Locate and maintain the loose parts, e.g. isolators, temperature sensors,
flow sensors or other factory-ordered, field-installed options, for installa-
tion, as required. Loose parts are located in the starter/control panel.
• Install the unit on a foundation with flat support surfaces, level within
1/4” (6.35 mm) and of sufficient strength to support concentrated load-
ing. Place the manufacturer-supplied isolation pad assemblies under the
unit.
• Install the unit per the instructions outlined in the Mechanical Installation
Table 2 Installation Responsibility Chart for RTHD Units
Requirement
Trane-supplied,
Trane-installed
Trane-supplied,
Field-installed
Field-supplied,
Field-installed
Rigging Safety chains
Clevis connectors - Lifting beam
Isolation Isolation pads Isolation pads
Electrical Circuit breakers or non-fused
disconnects (optional)
Circuit breaker or non-fused
disconnect handle
Circuit breakers or fusible discon-
nects (optional)
Unit-mounted starter Temperature sensor (optional
outdoor air)
Terminal lugs
Flow switches (may be field-
supplied)
Ground connection(s)
Condenser water regulating valve
controller (optional: may be field-
supplied)
Jumper bars
BAS wiring (optional)
IPC wiring
Control voltage wiring
High condenser pressure interlock
wiring
Chilled water pump contactor and
wiring
Condenser water pump contactor
and wiring
Optional relays and wiring
Water piping Flow switches (may be field-
supplied)
Thermometers
Condenser water regulating valve
controller (optional: may be field-
supplied)
Water flow pressure gauges
Isolation and balancing valves water
piping
Vents and drain valves
Pressure relief valves (for water
boxes as required)
Pressure Relief Relief valves Vent line and flexible connector
Insulation Insulation (optional) Insulation
