RTHD-SVX01D-EN 119
Unit Start-up
Stopped to Starting:
The stopped to starting diagram shows the timing from a stopped mode to
energizing the compressor. The shortest allowable time would be under the
following conditions:
1. No motor restart inhibit
2. Evaporator and Condenser Water flowing
3. Power up Start Delay Timer has expired
4. Adjustable Stop to Start Timer has expired
5. Need to cool
The above conditions would allow the compressor to start in 60 seconds
