Trane RTHD

26 RTHD-SVX01D-EN
Installation Mechanical
Table 9 Rigging
Unit
Configuration*
Dimension (mm (in))
ABCDEF
E3G3G3 3658 3353 1621 20 661 610
(144.02) (132.01) (63.82) (0.79) (26.02) (24.02)
E3G2G1 3658 3353 1621 20 661 610
(144.02) (132.01) (63.82) (0.79) (26.02) (24.02)
E3F2F3 3658 3353 1612 29 615 610
(144.02) (132.01) (63.46) (1.14) (24.21) (24.02)
E3D2E2 3048 2743 1525 116 612 610
(120.00) (107.99) (60.04) (4.57) (24.09) (24.02)
D3G3G3 3658 3353 1612 99 654 610
(144.02) (132.01) (63.46) (3.90) (25.75) (24.02)
D3G2G1 3658 3353 1612 99 654 610
(144.02) (132.01) (63.46) (3.90) (25.75) (24.02)
D3F2F3 3658 3353 1610 101 617 610
(144.02) (132.01) (63.39) (3.98) (24.29) (24.02)
D3D2E2 3048 2743 1523 188 614 610
(120.00) (107.99) (59.96) (7.40) (24.17) (24.02)
D2G3G3 3658 3353 1612 99 654 610
(144.02) (132.01) (63.46) (3.90) (25.75) (24.02)
D2G2G1 3658 3353 1612 99 654 610
(144.02) (132.01) (63.46) (3.90) (25.75) (24.02)
D2F2F3 3658 3353 1610 101 617 610
(144.02) (132.01) (63.39) (3.98) (24.29) (24.02)
D2D2E2 3048 2743 1523 188 614 610
(120.00) (107.99) (59.96) (7.40) (24.17) (24.02)
D1G2G2 3658 3353 1614 97 661 610
(144.02) (132.01) (63.54) (3.82) (26.02) (24.02)
D1G1G1 3658 3353 1612 99 654 610
(144.02) (132.01) (63.46) (3.90) (25.75) (24.02)
D1F1F2 3658 3353 1612 99 622 610
(144.02) (132.01) (63.46) (3.90) (24.49) (24.02)
D1D1E1 3048 2743 1524 187 612 610
(120.00) (107.99) 60.00) (7.36) (24.09) (24.02)
C2F2F3 3658 3353 1610 101 617 610
(144.02) (132.01) 63.39) (3.98) (24.29) (24.02)
C2D3E3 3048 2743 1517 225 618 610
(120.00) (107.99) (59.72) (8.86) (24.33) (24.02)
C2D4E4 3048 2743 1523 219 584 610
(120.00) (107.99) (59.96) (8.62) (22.99) (24.02)
*Designator corresponds to digits 6, 7, 14, 15, 21, 22 of model number
