Trane RTHD

RTHD-SVX01D-EN 27
Installation Mechanical
C1E1F1 3658 3353 1613 129 624 610
(144.02) (132.01) (63.50) (5.08) (24.57) (24.02)
C1D5E4 3048 2743 1523 219 584 610
(120.00) (107.99) (59.96) (8.62) (22.99) (24.02)
C1D6E5 3048 2743 1524 218 582 610
(120.00) (107.99) (60.00) (8.58) (22.91) (24.02)
B2C2D2 3658 3353 1481 93 523 610
(144.02) (132.01) (58.31) (3.66) (20.59) (24.02)
B2B2B2 3048 2743 1476 98 535 610
(120.00) (107.99) (58.11) (3.86) (21.06) (24.02)
B1C1D1 3658 3353 1479 95 521 610
(144.02) (132.01) (58.23) (3.74) (20.51) (24.02)
B1B1B1 3048 2743 1447 97 534 610
(120.00) (107.99) (56.97) (3.82) (21.02) (24.02)
Table 9 Rigging
Unit
Configuration*
Dimension (mm (in))
ABCDEF
*Designator corresponds to digits 6, 7, 14, 15, 21, 22 of model number
