Unit Start-up
Job Name Job Location
Model # Serial # start date:
Sales Order # ship date: Job elevation (ft. above sea level)
STARTER DATA: START-UP ONLY
Manufacturer Chiller appearance at arrival:
Type: (solid state, wye-delta) Compressor shipping bolts removed? Y N
Vendor ID #/Model #: Oil separator shipping bolts removed? Y N
Volts Amps Hz Machine Gauge Pressure: psig/ kPag
COMPRESSOR DATA: Machine CH530 Pressure: psig/ kPag
Model #: Complete if pressure test is required
Serial #: Vacuum after leak test= mm
NAMEPLATE DATA: Standing vacuum test = mm rise in hrs
RLA KW Volts UNIT CHARGES
50 60 Hz
DESIGN DATA: Unit refrigerant charge: lbs/ Kg
RLA KW Volts Unit Oil Charge: gal/ L
CURRENT TRANSFORMER SUMMARY OF UNIT OPTIONS INSTALLED
Part Number (“X” code and 2-digit extension) Y N Tracer Communications Interface
Primary CT’s Y N Options Module
X - Y N Outdoor Air Sensor
X - Y N Ice Making Control
X - Y N Other
DESIGN CONDITIONS
Evap Desig ________GPM L/S _________ PSID kPad Ent. Water F/C__________ Leaving Water F/C_________
Evap Actual ________GPM L/S _________ PSID kPad Ent. Water F/C__________ Leaving Water F/C_________
Cond Design ________GPM L/S _________ PSID kPad Ent. Water F/C__________ Leaving Water F/C_________
Cond Actual ________GPM L/S _________ PSID kPad Ent. Water F/C__________ Leaving Water F/C_________
Owner Witness Signature: _________________________________________________
Series R Start-up Test Log
