Diagnostics
5D2 Comm Loss:
Slide Valve Load
Normal Latch Continual loss of communication between the MP
and the Functional ID has occurred for a 30 second
period.
Remote
5D1 Comm Loss:
Slide Valve
Unload
Normal Latch Continual loss of communication between the MP
and the Functional ID has occurred for a 30 second
period.
Remote
6B6 Comm Loss:
Solid State Starter
Fault Input
Info Latch Continual loss of communication between the MP
and the Functional ID has occurred for a 30 second
period.
Remote
690 Comm Loss:
Starter
Immediate Latch Continual loss of communication between the MP
and the Functional ID has occurred for a 30 second
period.
Local
1F5 Compressor Did
Not Accelerate
Fully
Immediate Latch The starter module did not receive an "Up to Speed"
or "End of Ramp" signal from the SSS within 2.5
seconds after commanding a bypass, or after the
maximum acceleration time had expired, whichever
is longer. This diagnostic only applies to SSS.
Local
EE Compressor Did
Not Accelerate:
Shutdown
Immediate Latch The compressor did not come up to speed (get to
<85%RLA) in the allotted time defined by the
Maximum Acceleration Timer and and the start was
aborted per the starter configuration selected.
Remote
1FA Compressor Did
Not Accelerate:
Transition
Info Latch The compressor did not come up to speed (get to
<85%RLA) in the allotted time defined by the
Maximum Acceleration Timer and a transition was
forced (motor put across the line) at that time. This
applies to all starter types. Note: Since RTHD SSS
has no forced transition capability, this info warning
can be followed with a "Compressor did not accel-
erate fully " diagnostic above and an aborted start.
Remote
284 Compressor
Discharge
Temperature
Sensor
Immediate Latch Bad Sensor or LLID Remote
9A Condenser
Entering Water
Temperature
Sensor
Info and
Special
Action
Latch Bad Sensor or LLID. If chiller running, and condenser
water regulating valve option installed, force valve to
100% flow.
Remote
9B Condenser
Leaving Water
Temperature
Sensor
Info Latch Bad Sensor or LLID Remote
5B8 Condenser
Refrigerant
Pressure Trans-
ducer
Normal Latch Bad Sensor or LLID Remote
Table 33 Diagnostic List
Hex
Code
Diagnostic
Name and
Source Severity Persistence Criteria
Reset
Level
