RTHD-SVX01D-EN 157
Diagnostics
5C9 Starter Module
Memory Error
Type 2 -
Immediate Latch Checksum on EEPROM copy of the Starter LLID
configuration failed. Factor default values used.
Local
3D7 Transition
Complete Input
Opened
Immediate Latch The Transition Complete input is open with the
compressor motor running after a successful
completion of transition. This is active only for all
electromechanical starters
Local
3D5 Transition
Complete Input
Shorted
Immediate Latch The Transition Complete input is shorted before the
compressor was started. This is active for all
electromechanical starters.
Local
D8 Under Voltage Normal NonLatch a. Average of all monitored Line voltages below -
10% of nominal or the Under/Overvoltage trans-
former(s) are not connected. [Must hold = - 10 % of
nominal. Must trip = - 15 % of nominal. Reset differ-
ential = min. of 2% and max. of 4%. Time to trip =
min. of 1 min. and max. of 5 min.) Design: Nom.
trip: 60 seconds at less than 87.5%, + or - 2.8% at
200V or + or - 1.8% at 575V, Auto Reset at 90% or
greater.
Remote
Table 33 Diagnostic List
Hex
Code
Diagnostic
Name and
Source Severity Persistence Criteria
Reset
Level
