Trane RTHD

RTHD-SVX01D-EN 17
General Information
Table 6 General Data
Unit Designator (corresponds to digits 6, 7, 14, 15, 21, 22 of unit model number)
C2F2F3 B1B1B1 B1C1D1 B2B2B2 B2C2D2
General
Refrigerant Type
HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a
Refrigerant Charge (lb (kg))
700 (318) 410 (186) 490 ((222) 410 (186) 490 ((222)
Oil Charge (gal (l))
11 (42) 4.5 (17.0) 4.5 (17.0) 4.5 (17.0) 4.5 (17.0)
Operating Weight (lb (kg))
17560 (7965) 9867 (4476) 10554 (4787) 10019 (4544) 10653 (4832)
Shipping Weight (lb (kg))
16168 (7334) 9292 (4215) 9837 (4462) 9402 (4265) 9953 (4515)
Overall Dimensions
Length (in (mm))*
144 (3658) 124 (3160) 143 (3624) 124 (3160) 143 (3624)
Width (in (mm))*
68 (1727) 64 (1634) 64 (1634) 64 (1634) 64 (1634)
Height (in (mm))*
76 (1930) 73 (1849) 73 (1849) 73 (1849) 72 (1849)
Evaporator
Water Storage (gal (l))
107 (405) 41 (155) 55 (208) 45 (170) 58 (220)
Minimum Flow (gpm (l/s))
Water
604 (38) for
2-pass
253 (16) for
2-pass
320 (18) for
2-pass
288 (22) for
2-pass
347 (22) for
2-pass
404 (25) for
3-pass
168 (11) for
3-pass
213 (12) for
3-pass
192 (15) for
3-pass
232 (15) for
3-pass
Minimum Flow (gpm (l/s))
Brine
725 (46) for
2-pass
303 (19) for
2-pass
346 (22) for
2-pass
346 (22) for
2-pass
375 (24) for
2-pass
487 (31) for
3-pass
200 (13) for
3-pass
254 (16) for
3-pass
233 (15) for
3-pass
276 (17) for
3-pass
Maximum Flow (gpm (l/s))
2667 (168)
for 2-pass
1104 (70) for
2-pass
1412 (89) for
2-pass
1266 (80) for
2-pass
1531 (97) for
2-pass
1780 (112)
for 3-pass
736 (46) for
3-pass
941 (59) for
3-pass
844 (53) for
3-pass
1022 (65) for
3-pass
Condenser
(all are 2-pass)
Water Storage (gal (l))
61 (231) 28 (106) 31 (117) 29 (110) 34 (129)
Minimum Flow (gpm (l/s))
Water
355 (22) 193 (12) 193 (12) 212 (13) 212 (13)
Minimum Flow (gpm (l/s))
Brine
460 (29) 230 (15) 230 (15) 255 (16) 255 (16)
Maximum Flow (gpm (l/s))
1700 (107) 850 (54) 850 (54) 935 (59) 935 (59)
All weights ±3%, include standard 150 psig water boxes.
Operating weights include refrigerant, oil, and water charges.
If oil cooler is installed, add 1/4 gal (1 liter) to the oil charge value given for B family units; add 1.0 gal (4 liters) for all other units.
Overall dimensions are based on 3-pass evap/2 pass cond and LH/RH water connections. Refer to submittals for exact job configurations
