Trane RTHD

RTHD-SVX01D-EN 43
Installation Mechanical
Evaporator Pressure Drop
C Frame - 2 Pass
0
5
10
15
20
25
30
35
0 500 1000 1500
Flow (GPM)
Delt-P (Ft H
2
O)
C1
C2
Evaporator Pressure Drop
C Frame - 3 Pass
0
5
10
15
20
25
30
35
40
45
50
0 200 400 600 800 1000
Flow (GPM)
Delt-P (Ft H
2
O)
C1
C2
