RTHD-SVX01D-EN 63
Installation Electrical
Maximum Fuse/Circuit Breaker Size
The maximum fuse/circuit breaker size is equal to 2.25 x the compressor RLA
in accordance with UL 1995, para. 36.15.See also NEC 440-22.
The recommended dual element (RDE) fuse size is equal to 1.75 x RLA in
accordance with NEC Table 430-152.
For recommended field connection lug sizes (RTHD starters) see Table 14.
