Operator Interface Controls
Outdoor Air Temperature ± XXX.X F / C
Compressor
Compressor Starts XXXX Integer
Compressor Running Time XXXX:XX hr:min
System Rfgt Diff Pressure XXX.X psi / kPa
Oil Pressure XXX.X psi / kPa
Compressor Rfgt Discharge Temp
± XXX.X F / C
Discharge Superheat
± XXX.X F / C
% RLA L1 L2 L3 XXX.X Percent RLA
Amps L1 L2 L3 XXXX Amps
Volts AB BC CA XXXX Volts
ASHRAE Chiller Log
Current Time/Date XX:XX mmm dd, yyyy Date / Time
Operating Mode: Text
Amps L1 L2 L3 XXXX Amps
Volts AB BC CA XXXX Volts
Active Chilled Water Setpoint XXX.X F / C
Active Current Limit Setpoint XXX.X F / C
Refrigerant Monitor XXX.X Ppm
Compressor Starts XXXX Integer
Compressor Running Time XX:XX Hours:Minute
Compressor Rfgt Discharge Temp XXX.X F / C
Evap Entering Water Temp XXX.X F / C
Evap Leaving Water Temp XXX.X F / C
Evap Sat Refrigerant Temp XXX.X F / C
Evap Rfgt Pressure XXX.X psi / kPa
Evap Approach Temp: XXX.X F / C
Evap Water Flow Switch Status Text
Cond Entering Water Temp XXX.X F / C
Cond Leaving Water Temp XXX.X F / C
Cond Sat Rfgt Temp XXX.X F / C
Cond Rfgt Pressure XXX.X psi / kPa
Condenser Approach Temp XXX.X F / C
Cond Water Flow Switch Status Text
Table 19 Report Screen Items
Description Resolution Units
