Chapter 7 Commands
TransCore Proprietary
7–107
Table 26 Open/Closed Conditions for Output Status (IAG Applications)
Output
Status
Output0 Wire Pair Output1 Wire Pair
Orange
Jumper to
Black of
Brown/Black
Brown/Black
White
Jumper to
Black of
Green/Black
Green/Black
O0 Closed Open Closed Open
O1
Open Closed Closed Open
O2
Closed Open Open Closed
O3
Open Closed Open
Closed
Table 27 shows the input0 and input1 open/closed conditions for the input status displays.
Table 27 Open/Closed Conditions for Input Status
Input
Status
Input0 Wire Pair Input1 Wire Pair
Green/Red Blue/Black
I0 Open Open
I1 Closed Open
I2 Open Closed
I3 Closed Closed
527 Display RF Status
Command #527 displays the current status of the RF module. The reader response indicates whether RF
is controlled externally by the host, set by command #640N RF Control, or internally by input set by
command #641. Command #527 also displays the current RF status and the uniqueness timeout.
Note: If you enter RF frequency settings using command #642NN, the display command for RF
output frequency, F is “Fxx” and indicates use of the backward-compatible frequency entry method.
Reader message:
RFST C<0 to 1> O<0 to 1> T<1 to 3> Fxxx Rxx Gxx Axx Ixx
where
C0 RF controlled by host (#6400, #6401)
C1 RF controlled by presence sensor on input0, the red/green pair (factory default)
(#641)
O0 RF o (#6400)
O1 RF on (#6401)
T1 Uniqueness timeout of two minutes (#441)
