As an example, a label reading 10-4002-004 indicates that this 915-MHz Encompass 4 Reader is
configured with an integrated antenna, RS–232 and Wiegand communications, and reads SeGo and IAG
protocol tags.
Default Operating Parameter Settings
Table 43 contains the factory default configuration settings for the Encompass 4 Reader operating
parameters. The default configuration settings may not be the correct operating configuration settings for
a specific site. Changes to the configuration settings may have to be made, depending on the site plan, as
described in “Chapter 2 Developing the Site Plan” on page 2–4.
Review the default configurations shown in Table 43 to determine which parameters, in addition to
operating frequency and operating range, need to be adjusted. Refer to “Chapter 7 Commands” on page
7–86 for a complete list of parameters and the corresponding commands.
Note: The dual-protocol Encompass 4 Reader internal timing varies depending on the operative tag
read mode and the type of tag in the read field.
Table 43 Encompass 4 Reader Default Configuration Settings
Parameter Setting Command
Operating mode Data 00
Baud rate 9600 1005
Stop bits 1 1010
Parity None 1020
Time and date appended Enabled 302
Auxiliary information appended Disabled 310
Unique ID code criteria Separation of 1 ID 4100
Wiegand mode Disabled 450
Tag translation mode Disabled 452
Multi-tag sort Disabled 454
eGo and eGo Plus tag initialization
during multi-tag sort
Enabled 456
Second alternative group select Disabled 458
Wiegand transmit mode 1 second 4601
Third alternative group select Disabled 490
Fourth alternative group select Disabled 492
Fifth alternative group select Disabled 494
Alternate group select Disabled 496
Reader ID number
00 6000
Encompass 4 Reader System Guide
