-24-
The router table fence features fully independent
fence cheeks which allow the fence to double as
a vertical planer for a 1.4mm or 2.4mm offset.
To set up for edge planing, remove the two joint-
ing rods which are stored in the top slot of the
fence, loosen the outfeed fence cheek and place
the rods into the shallow recesses behind the
outfeed fence.
Edge Planing
To position the fence at the 1.4mm setting, slide
the rods into the deeper recesses, as shown be-
low and tighten the fence cheeks locking knobs.
To position the fence at the 2.4mm setting, slide
1.4mm offset
2.4mm offset
The rods can be parked in the T-slots in the top
of the back fence. The rods are held by tighten-
ing the knobs.
the rods into the shallower recesses, as shown
below and tighten the fence cheeks locking
knobs.
After use of the table, keep assembled and
store properly.
