WRT - SPARE PARTS LIST v1.0 03/2017
No. Qty. Desc. Ref.
1 1 Table Top WP-WRT/01
2 1 Insert Plate WP-WRT/02
3 1 Back Fence WP-WRT/03
4 2 Fence Cheek WP-WRT/04
5 1 Top Frame WP-WRT/05
6 2 Crossbar WP-WRT/06
7 2 Legs WP-WRT/07
8 2 Edge Planing Rod WP-WRT/08
9 2 T-Nut for Edge Planing Knob WP-WRT/09
10 1 No Volt Release Switch 240V UK Plug NVRS/2/240V
1 No Volt Release Switch 230V EURO Plug NVRS/2/230V/E
11 2 Spring for Edge Planing Knob WP-CRTMK3/11
12 2 Knob for Edge Planing Assembly WP-CRTMK3/12
13 4 Knob UNC 1/4 - 20 x 3/4” Male for Fence Cheek WP-CRTMK3/13
14 2 Washer 8mm x 23mm x 2mm for Back Fence Knob WP-CRTMK3/14
15 2 Back Fence Knob UNC 5/16 Female WP-CRTMK3/15
16 1 Dust Spout WP-CRTMK3/16
17 2 Machine Screw M4 x 8mm Pozi for Dust Spout WP-CRTMK3/17
18 2 T Bolt UNC 1/4 - 20 x 1-3/4” for Top Guard WP-CRTMK3/18
19 2 Washer for T Bolt WP-CRTMK3/19
20 1 Top Pressure WP-CRTMK3/20
21 1 Top Guard WP-CRTMK3/21
22 2 Washer Plastic for Top Guard WP-CRTMK3/22
23 2 Knob UNC 1/4 - 20 Female for Plastic Guard WP-CRTMK3/23
24 2 Knob for Side Pressure WP-CRTMK3/24
25 2 Washer 8mm x 23mm x 2mm for Side Pressure Bolt WP-CRTMK3/25
26 1 Side Pressure WP-CRTMK3/26
27 2 Hook for Pushstick WRT WP-WRT/27
28 2 Plate for Side Pressure Bolt WP-CRTMK3/28
29 2 Machine Screw Csk 1/4” x 1-9/16” Phillips WP-CRTMK3/29
30 7 Set Screw M6 x 6mm for Fixing Plate WP-CRTMK3/30
31 3 Machine Screw Csk M6 x 15mm Phillips WP-CRTMK3/31
32 1 Insert Ring 31.8mm ID WP-CRTMK3/32
33 1 Insert Ring 67.5mm ID WP-CRTMK3/33
34 4 Machine Screw Csk M5 x 16mm Skt WP-CRTMK3/34
35 1 Lead-on Pin WP-CRTMK3/35
36 4 Magnet 8mm x 5mm WP-CRTMK3/36
37 1 Self Tapping Screw for Mitre Fence Extrusion WP-CRTMK3/37
38 1 Mitre Fence Extrusion WP-WRT/38
39 2 T Bolt UNC 1/4 x 1-1/4” x 2” Male for Back Fence WP-WRT/39
40 2 Switch Bracket WP-CRTMK3/40
