TRENDnet User’s Guide
TEW-814DAP
• Network Key: Select the Key number you would like to use and enter the WEP
key. This is the password or key that is used to connect your computer to this
access point wirelessly.
Selecting WPA-Personal
In the Security Mode drop-down list, select WPA-Personal; Please review the WPA-
Personal settings to configure and click Apply to save the changes.
• Security Mode: Select WPA-Personal
• WPA Mode: Select WPA2 Only, WPA Only or Auto (WPA or WPA2). It is
recommended to select WPA2 Only, but if you are not certain you can select Auto.
• Cipher Type: Select AES when using WPA2 only, TKIP when using WPA Only. You
can select TKIP and AES when using Auto (WPA or WPA2)
• Pre-Shared Key: Enter the security password. This is the password or key that is
used to connect your computer to this access point wirelessly.
Selecting WPA Enterprise:
The following section outlines options when selecting WPA (EAP or RADIUS). This
security type is also known as EAP (Extensible Authentication Protocol) or Remote
Authentication Dial-In User Service or RADIUS.
Note: This security type requires an external RADIUS server, Pre-Shared Key only requires
you to create a passphrase.
• Security Mode: Select WPA-Enterprise
• WPA Mode: Select WPA2 Only, WPA Only or Auto (WPA or WPA2). It is
recommended to select WPA2 Only, but if you are not certain you can select Auto.
• Cipher Type: Select AES when using WPA2 only, TKIP when using WPA Only. You
can select TKIP and AES when using Auto (WPA or WPA2)
• RADIUS Server IP Address: Enter the IP address of the RADIUS server. (e.g.
192.168.10.250)
• RADIUS Port: Enter the port your RADIUS server is configured to use for RADIUS
authentication.
Note: It is recommended to use port 1812 which is typical default RADIUS port.
• RADIUS server Shared Secret: Enter the shared secret used to authorize your
access point with your RADIUS server.
WEP Key Format HEX ASCII
Character set 0-9 & A-F, a-f only Alphanumeric (a,b,C,?,*, /,1,2, etc.)
64-bit key length 10 characters 5 characters
128-bit key length 26 characters 13 characters
