TRENDnet User’s Guide
TI-PG1284i
115
Default - deletes existing announce interval from PTP port and
adds default interval (1).
Announce Timeout
Add - configures specified value as announce time in PTP port.
Default - deletes existing announce timeout from PTP port and
adds default timeout (3).
Vlan ID
Add - configures specified VLAN list to PTP port.
Remove - deletes specified VLAN list from PTP port.
Static Route
Static routes, which define explicit paths between two routers, cannot be automatically
updated; you must manually reconfigure static routes when network changes occur.
Static routes use less bandwidth than dynamic routes. No CPU cycles are used to calculate
and analyze routing updates.
IP forwarding
IP forwarding provides on end to end delivery of IP packet between hosts with help of
routers. Routing database plays import role in forwarding the packets. Routers populate
its routing database either by manual configurations or by using dynamic routing
protocols.
IP forwarding works as router as well as Inter VLAN routing with trunk stick.
Manual routing configurations are called as Static routes. Static routes are permanent
routes; we can delete those routes with manual configurations only.
Whenever an IP packet received by a router then it fetches destination IP address and it
will do the lookup in routing table to find the longest prefix match route. Packet is
forwarded on the assigned next-hop in the route.
CLI Configuration
Node
Command
Description
enable
show ip forwarding
status
This command displays the current
configuration of the ip forwarding status.
enable
show ip routes
(all|ipv4|ipv6)
This command displays the configurations of
IPv4 or IPv6 or both routes from routing table.
enable
show ip arp
(all|ipv4|ipv6)
This command displays dynamic and static IPv4
or IPv6 or both ARP entries in ARP table.
enable
show ip hosts
(all|ipv4|ipv6)
This command displays assigned IPv4 or IPv6
or both addresses for interfaces in router.
configure
ip forwarding enable
This command enables layer 3 IPv4 and IPv6
forwarding/routing globally.
configure
no ip forwarding
enable
This command disables layer 3 IPv4 and IPv6
forwarding/routing globally.
This will delete all assigned IP addresses and
static routes from interfaces.
configure
ip arp proxy enable
This command enables route to act as an ARP
proxy globally; It will be useful in InterVLAN
routing.
configure
no ip arp proxy
enable
This command disables route to act as an ARP
proxy.
configure
ipv4 arp <IPv4_ADDR>
<MAC_ADDR>
This command allows adding static IPv4 ARP
entry in ARP table.
configure
ip6 arp <IPv6_ADDR>
<MAC_ADDR>
This command allows adding static IPv6 ARP
entry in ARP table.
configure
no ipv4 arp
<IPv4_ADDR>
<MAC_ADDR>
This command deletes a static IPv4 ARP entry
from ARP table.
configure
no ipv6 arp
<IPv6_ADDR>
<MAC_ADDR>
This command deletes a static IPv6 ARP entry
from ARP table.
configure
interface vlan VLAN-
ID
This command enters the L3 interface node.
L3
interface
ipv4 address
A.B.C.D/M
This command assigns a specified IPv4
interface route to the interface.
