TRENDnet User’s Guide
TI-PG1284i
52
MVR
MVR refers to Multicast VLAN Registration that enables a media server to transmit
multicast stream in a single multicast VLAN while clients receiving multicast VLAN stream
can reside in different VLANs. Clients in different VLANs intend to join or leave the
multicast group simply by sending the IGMP Join/leave message to a receiver port. The
receiver port belonging to one of the multicast groups can receive multicast stream from
media server. Without support of MVR, the Multicast stream from media server and
subscriber must reside in the same VLAN.
 Source ports : The Stream source ports.
 Receiver ports : The Client ports.
 Tagged ports : Configure the tagged ports for source ports or receiver ports.
MVR Mode
 Dynamic Mode:
If we select the dynamic mode in MVR setting, IGMP report message transmitted
from the receiver port will be forwarded to a multicast router through its source
port. Multicast router knows which multicast groups exist on which interface
dynamically.
 Compatible mode:
If we select the dynamic mode in MVR setting, IGMP report message transmitted
from the receiver port will not be transmitted to a multicast router.
Operation Mode
 Join Operation:
A subscriber sends an IGMP report message to the switch to join the appropriate
multicast. The next depends on whether the IGMP report matches the switch
configured multicast MAC address. If it matches, the switch CPU modifies the
hardware address table to include this receiver port and VLAN as a forwarding
destination of MVLAN.
 Leave Operation:
Subscriber sends an IGMP leave message to the switch to leave the multicast. The
switch CPU sends an IGMP group-specific query through the receiver port VLAN. If
there is another subscriber in the VLAN, subscriber must respond within the max
response time. If there is no subscriber, the switch would eliminate this receiver
port.
 Immediate Leave Operation:
Subscriber sends an IGMP leave message to the switch to leave the multicast.
Subscribers do not need to wait for the switch CPU to send an IGMP group-specific
query through the receiver port VLAN. The switch will immediately eliminate this
receiver port.

TRENDnet TI-PG1284i Specifications

General

Switch type	Managed
Switch layer	L2+
System event log	Yes
10G support	No
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Tagged VLAN, Protocol-based VLAN
Console port	RJ-45
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	-
Certification	CE, FCC
Product color	Black
International Protection (IP) code	IP30
Throughput	17.86 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Packet buffer memory	128 MB
DHCP features	DHCP server
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SNMP
Multicast MAC address table	256 entries
Output current	5 A
Output voltage	48 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	260 W
Total Power over Ethernet (PoE) budget	240 W
Power over Ethernet (PoE) power per port	30 W
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	0 - 95 %
Mean time between failures (MTBF)	322805 h
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	132 mm
Width	170 mm
Height	50 mm
Weight	920 g
