TRENDnet TI-PG1284i User Manual

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Table of Contents
i
Contents
Product Overview ........................................................................... 1
Package Contents .......................................................................................................... 1
Features ......................................................................................................................... 1
Product Hardware Features........................................................................................... 3
SFP Transceiver/Optical Cable Installation .................................................................... 5
Switch Installation .......................................................................... 6
DIN-Rail Installation ....................................................................................................... 6
Install power supply connections .................................................................................. 7
Basic IP Configuration .................................................................................................... 7
Connect additional devices to your switch .................................................................... 9
Accessing switch management interfaces ...................................... 10
Access your switch command line interface................................................................ 10
CLI Command Modes ......................................................................................... 11
Access your switch web management page ................................................................ 12
System Information....................................................................... 13
Basic Settings ................................................................................ 14
General Settings .......................................................................................................... 14
System ............................................................................................................... 14
Jumbo Frame ..................................................................................................... 17
SNTP ................................................................................................................... 18
Management Host ............................................................................................. 21
MAC Management ....................................................................................................... 22
Static MAC Settings ............................................................................................ 22
MAC Table .......................................................................................................... 24
Age Time Settings .............................................................................................. 24
Refusal (Black-hole MAC) ................................................................................... 24
Port Mirror ................................................................................................................... 26
Port Settings ................................................................................................................ 28
General Settings ................................................................................................ 29
Information ........................................................................................................ 31
Advanced Settings ........................................................................ 32
Bandwidth Control ...................................................................................................... 32
QoS .................................................................................................................... 32
Rate Limitation .................................................................................................. 38
IGMP Snooping ............................................................................................................ 41
IGMP Snooping .................................................................................................. 41
IGMP Filtering .................................................................................................... 46
Multicast Listener Discovery (MLD) Snooping ................................................... 49
MVR ................................................................................................................... 52
Multicast Address .............................................................................................. 56
Explicit Host Tracking ......................................................................................... 58
VLAN ............................................................................................................................ 59
Port Isolation ..................................................................................................... 59
802.1Q VLAN ...................................................................................................... 60
GARP/GVRP ....................................................................................................... 65
MAC-based VLAN ............................................................................................... 67
Protocol-based VLAN ......................................................................................... 68
Q-in-Q VLAN (VLAN Stacking) ............................................................................ 69
DHCP Option 82 ........................................................................................................... 76
DHCP Relay .................................................................................................................. 79
Dual Homing ................................................................................................................ 81
ERPS ............................................................................................................................. 83
Link Aggregation .......................................................................................................... 87
Link Layer Discovery Protocol (LLDP) ........................................................................... 91
Loop Detection ............................................................................................................ 94
Modbus ........................................................................................................................ 96
PoE (Power over Ethernet) ........................................................................................ 100
PTP (IEEE-1588 v2) ..................................................................................................... 106

TRENDnet TI-PG1284i Specifications

General

Switch type	Managed
Switch layer	L2+
System event log	Yes
10G support	No
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Tagged VLAN, Protocol-based VLAN
Console port	RJ-45
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	-
Certification	CE, FCC
Product color	Black
International Protection (IP) code	IP30
Throughput	17.86 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Packet buffer memory	128 MB
DHCP features	DHCP server
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SNMP
Multicast MAC address table	256 entries
Output current	5 A
Output voltage	48 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	260 W
Total Power over Ethernet (PoE) budget	240 W
Power over Ethernet (PoE) power per port	30 W
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	0 - 95 %
Mean time between failures (MTBF)	322805 h
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	132 mm
Width	170 mm
Height	50 mm
Weight	920 g
