TRENDnet User’s Guide
TI-PG1284i
169
View Type
Select included or excluded to define subtree adding to the view
or not.
Apply
Click Apply to configure the settings.
Refresh
Click Refresh to begin configuring this screen afresh.
SNMPv3 View Status
View Name
This field displays the v3 view name.
View Subtree
This field displays the subtree.
View Type
This field displays the subtree adding to the view or not.
Action
Click Delete to remove a v3 view.
Auto Provision
Auto provision is a service that service provider can quickly, easily and automatically
configure remote device or doing firmware upgrade at remote side.
1. When the Auto Provision is enabled, the Switch will download the auto provision
information file from the auto provision server first.
The file name is followed below naming rule:
Model_Name_Autoprovision.txt
For Example: SWITCH_Autoprovision.txt
The contents of the file are listed below:
AUTO_PROVISION_VER=1
Firmware_Upgrade_State=1
Firmware_Version=8648P-999-1.1.0.S0
Firmware_Image_File=8648P-999-1.1.0.S0.fw
Firmware_Reboot=1
Global_Configuration_State=0
Global_Configuration_File=8648P-999-1.1.0.S0.save
Global_Configuration_Reboot=0
Specific_Configuration_State=0
Specific_Configuration_Reboot=0
2. If AUTO_PROVISION_VER is biggest than current auto provision version, do step 3;
otherwise, wait 24 hours and go back to step 1.
3. If the Firmware_Upgrade_State =1, do step 4; otherwise, do step 6.
4. If the Firmware_Version is difference than current firmware version, download the
Firmware_Image_File and upgrade firmware.
5. If upgrade firmware succeeded and Firmware_Reboot=1, let reboot_flag=1.
6. If the Global_Configuration_State =1, download the Global_Configuration_File and
upgrade configuration; otherwise, do step 8.
7. If upgrade configutation succeeded and Global_Configuration_Reboot =1, let
reboot_flag=1.
8. If the Specific_Configuration_State =1, download the specific configuration file and
upgrade configuration; otherwise do step 10. The naming is “Model_Name _” with
12-bit MAC digits ,example for following is “INS-8648P_00e04c8196b9.txt”
9. If upgrade configutation succeeded and Specific_Configuration_Reboot =1, let
reboot_flag=1.
10. If reboot_flag=1, save running configuration and reboot the switch; otherwise, wait
24 hours and go back to step 1.

TRENDnet TI-PG1284i Specifications

General

Switch type	Managed
Switch layer	L2+
System event log	Yes
10G support	No
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Tagged VLAN, Protocol-based VLAN
Console port	RJ-45
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	-
Certification	CE, FCC
Product color	Black
International Protection (IP) code	IP30
Throughput	17.86 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Packet buffer memory	128 MB
DHCP features	DHCP server
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SNMP
Multicast MAC address table	256 entries
Output current	5 A
Output voltage	48 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	260 W
Total Power over Ethernet (PoE) budget	240 W
Power over Ethernet (PoE) power per port	30 W
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	0 - 95 %
Mean time between failures (MTBF)	322805 h
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	132 mm
Width	170 mm
Height	50 mm
Weight	920 g
