TRENDnet TI-PG1284i User Manual

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
2
Full PoE+ Power Budget
Supplies up to 30 Watts of PoE/PoE+ power per port with a 240 Watt PoE power budget
Network Ports and Capacity
8 x Gigabit PoE+ ports and 4 x Gigabit SFP slots allow for a 24Gbps switching capacity
and 1 x console (RJ-45 to RS-232) for out-of-band management
Integrated DIN-Rail Mount
IP30 rated metal enclosure with integrated DIN-Rail mounting hardware
Full PoE Control Per Port
PoE control features include enabling/disabling PoE and class, power priority, PD alive
check, scheduling, and power delay per port using CLI or web management.
Traffic Management
Managed features include 802.1Q/Q-in-Q/GVRP/MAC & Protocol-Based VLAN, IGMP
v1/2/3, IGMP Snooping, MLD, MVR, per port bandwidth control/802.1p/DSCP/Queue
Scheduling (SPQ/WRR), STP/RSTP/MSTP spanning tree, static and dynamic link
aggregation, and Xpress Ring + ERPS protection for flexible network integration.
Layer 2+ Management
Offers IPv4/IPv6 static or DHCPv4/v6 assignment, IPv4/IPv6 static routing and proxy
ARP, DHCP server/relay/option 82, and DHCP server snooping/screening to filter out
unauthorized DHCP servers
Access Controls
Management via HTTPS and SSH protocols and features such as trusted host, ACLs, IP-
MAC-Port binding, ARP inspection, 802.1X RADIUS, MAC address learning, IP Source
Guard provide layered network access controls.
System Monitoring
Monitoring features include SNMP v1/v2c/3, MIB support, SNMP trap, RMON Groups (1,
2, 3, 9), SMTP alert, syslog, port mirroring, SFP DDMI, and ModBus/TCP.
Redundant Power
Dual redundant power inputs (primary and RPS) with overload current protection
Alarm Output
Alarm relay output triggered by power failure of primary and/or redundant power and
failure per port (DIP switch)
Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 10K)
Wide Temperature
Hardened switch is rated for an operating temperature range of - 40 to 75 °C (-40 to 167
°F)
Electro Magnetic Compliance
Complies with IEC61000-6-2 EMC generic standard immunity for industrial
environments
Shock and Vibration Resistant
Rated for shock (IEC 60068-2-27), freefall (IEC 60068-2-32), and vibration (IEC 60068-2-
6)
LED Indicators
LED indicators convey power, redundant power, alarm, SFP, PoE, and network port
status
Grounding Point
Grounding point protects equipment from external electrical surges

TRENDnet TI-PG1284i Specifications

General

Switch type	Managed
Switch layer	L2+
System event log	Yes
10G support	No
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Tagged VLAN, Protocol-based VLAN
Console port	RJ-45
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	-
Certification	CE, FCC
Product color	Black
International Protection (IP) code	IP30
Throughput	17.86 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Packet buffer memory	128 MB
DHCP features	DHCP server
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SNMP
Multicast MAC address table	256 entries
Output current	5 A
Output voltage	48 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	260 W
Total Power over Ethernet (PoE) budget	240 W
Power over Ethernet (PoE) power per port	30 W
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	0 - 95 %
Mean time between failures (MTBF)	322805 h
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	132 mm
Width	170 mm
Height	50 mm
Weight	920 g
