12-10
TOPAZ
1. Sofa/Bed Conversion:
The sofa converts into a bed. To
convert to bed:
a. Remove seat pillows
b. Lift the sofa seat up from the
base.
c. Pull forward until the back drops
down to a bed position.
To convert back to a sofa:
a. Lift and push the sofa back
against the wall.
2. Dinette:
The standard dinette also can be
converted into a bed:
a. Remove cushions.
b. Lift table and remove the table
legs.
c. Drop table between seats so that
the edge of the table rests on
seat edge supports.
d. Arrange cushions to form a bed,
placing larger cushions in the
center.
To convert back to a dinette, reverse the
above instructions.
12.11 SLEEPING FACILITIES
Do not use sleeping facilities while trailer is in
motion.
Fig. 12-15 SOFA BED
Fig. 12-16 DINETTE (OPTIONAL)
WARNING
