6-17
TOPAZ
6.16 LANDING GEAR
Each fifth wheel trailer is designed with
landing gear to support the weight of the
front of the unit when the tow vehicle is
unhooked.
The landing gear can be lowered using a 12
volt motor (optional) or a manual crank.
Use powered switch located on front of unit
or use the crank. Always stow the crank
when not in use.
If equiped with power landing gear, a
manual overide on/off switch is located
inside the front baggage compartment.
Switch - Powered (Optional)
Fig. 6-20 LANDING GEAR
Crank - Manual
6.17 STABILIZER JACKS
Each corner of the trailer is or can be
equipped with stabilizer jacks to elimi-
nate frame movement when the trailer is
occupied.
Fig. 6-22 STABILIZER JACKS (TYPICAL)
Fig. 6-21 LANDING GEAR OVERRIDE SWITCH
