7-4
TOPAZ
7.3 SLIDE OUT ROOM (OPTIONAL)
A trailer may be equipped with an optional expandable, slide out room to provide more living area for the
occupants.
7.3.1 SLIDE OUT ROOM
Fig. 7-4 CONTROL PANEL
Follow this procedure when using slide out room:
1. Be sure that trailer is properly levelled and
supported with stabilizing jacks.
IMPORTANT
If the unit is not properly levelled
before extending the room, the
slide out mechanism may bind
and be damaged.
2. Before operating slide out:
a. If this is the first time you are operating the
slide-out,review the instructions that you
received from your dealer at the time of
delivery.
b. Level the trailer following the instructions in
Section 7.2.
c. Make sure there is adequate space beside
your trailer for the slide-out room to be
extended.
d. Remove the travel locks on slide unit.
e. Check the interior of the slide-out to make
sure there are no obstructions on the floor
or leaning against the walls. Close all
cabinet doors.
Fig. 7-5 TRAVEL LOCKS (TYPICAL)
Make sure travel locks are removed
before extending the slide-out.
Make sure travel locks are fastened
securely before moving the trailer.
WARNING
