Triple E Topaz - 11.3 Plumbing System Operation

11-10
11.2.6 HOLDING TANK
LEVEL INDICATORS
TOPAZ
11.3 PLUMBING SYSTEM
OPERATION
11.3.1 WATER HEATER
Your trailer is equipped with a 6
gallon water heater. The water
is heated in one of two ways:
1. With an LP gas burner.
2. With a 120-volt
heating element.
1. LP Gas Operation:
To ignite the heater, turn on
the waterheater switch
located in the kitchen. A
red light in the system
switch will come on when
the burner has ignited.
* Fresh water tank capacity includes water heater.
11.2.7 TANK CAPACITIES
The holding tank levels may be checked on
the control panel. Press the test switch to
check the level in each tank.
Fig. 11-11 TANK LEVEL INDICATORS
Fig. 11-12 WATER HEATER SWITCH
Fifth Wheel
Trailer
T240, T260, T271, T272SS, T290, F240, T300FS, FS250, F260RK, FS275,
F241SS, F260RB, FS270 FS305, FS320
U.S. GAL(Litres) U.S. GAL(Litres)
Fresh Water 46(175) 46(175)
Grey Water 36(136) 72(272)
Black Water 36(136) 36(136)
