6.8.2 WATER HEATER BYPASS
The water heater is equipped with a
valve that sets its plumbing circuit
for normal or winterize. The valve is
accessed from inside the trailer by
opening the bottom cabinet next to
the refrigerator. However, the
location can vary depending on your
specific configuration.
Watch the pointer on the pivot to
determine the valve setting.
1. Bypass Operation.
2. Normal Operation.
Refer to instruction sheet in informa-
tion package for more details on
winterizing procedure.
1. Bypass
2. Normal
Fig. 6-10 WATER HEATER DIVERTER VALVE
