6-18
TOPAZ
6.18 MANUAL SLIDE-OUT ROOM CRANK
Each trailer that is equipped with an
optional slide-out room, is designed with
a crank to extend or retract the room
manually. Use the crank to move the
room manually or as a back-up if there is
insufficient battery power.
Fig. 6-23 MANUAL SLIDE-OUT CRANK
6.19 HITCH LIGHT
The fifth wheel trailer kingpin area is designed
with a light to assist in seeing components in the
hitch area. Turn the light off when the hook-up
procedure has been completed.
Fig. 6-24 HITCH LIGHT
