Triumph Sprint GT User Manual

114
Maintenance and Adjustment
Turn Signal Lights
Front Turn Signal Bulb Replacement
1. Mirror glass
2. Securing screws
3. Bulb holder
Release the screws on the underside of the
mirror shell and remove the mirror glass to
gain access to the bulb holder.
Carefully remove the rubber bulb holder and
detach the bulb.
Installation is the reverse of the removal
procedure.
Rear Turn Signal Bulb Replacement
1. Tu r n s i g n a l l e n s
2. Lens screw
The lens on each turn signal light is held in
place by a screw located in the body of the
light.
Release the screws and remove the lens to
gain access to the bulb for replacement.
Installation is the reverse of the removal
procedure.
Caution
Support the mirror glass in case it falls out
when releasing the screws.
ccnz
1
2
3
ccoa
1
2

Triumph Sprint GT Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Fuel Tank Capacity	20 litres
Max Power	130 PS (95.6 kW) @ 9, 200 rpm
Max Torque	108 Nm @ 6, 300 rpm
Exhaust	Stainless steel 3 into 1
Frame	Aluminium beam
Front Suspension	43mm
Rear Suspension	Monoshock with adjustable preload and rebound damping
Front Brakes	Twin 320 mm floating discs, Nissin 4-piston calipers
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper
Seat Height	815mm
Ignition	Digital inductive type
Swingarm	Single-sided, aluminium alloy
Wheelbase	1, 537 mm
