Triumph Sprint GT User Manual

28
General Information
Fuel Gauge
1. Fuel gauge
The fuel gauge indicates the amount of fuel
in the tank.
With the ignition switched on, the number of
bars shown in the display indicates the level
of fuel in the tank.
When the fuel tank is full, all 10 bars are
displayed and when empty, no bars are
displayed. Other gauge markings indicate
intermediate fuel levels between full and
empty.
When 2 bars are displayed, the low fuel
warning light will illuminate. This indicates
there are approximately 1.05 US gal
(4.0 liters) of fuel remaining in the tank and
you should refuel at the earliest opportunity.
After refuelling, the fuel gauge and range to
empty information will be updated only while
riding the motorcycle.
Depending on the riding style, this could take
approximately 5 minutes.
Caution
Do not continue to run the engine if either
of the high temperature warnings are
displayed as severe engine damage may
result.
ccni
1

Triumph Sprint GT Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Fuel Tank Capacity	20 litres
Max Power	130 PS (95.6 kW) @ 9, 200 rpm
Max Torque	108 Nm @ 6, 300 rpm
Exhaust	Stainless steel 3 into 1
Frame	Aluminium beam
Front Suspension	43mm
Rear Suspension	Monoshock with adjustable preload and rebound damping
Front Brakes	Twin 320 mm floating discs, Nissin 4-piston calipers
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper
Seat Height	815mm
Ignition	Digital inductive type
Swingarm	Single-sided, aluminium alloy
Wheelbase	1, 537 mm
