Triumph Sprint GT User Manual

29
General Information
Warning Lights
Turn Signals
When the turn signal switch is
pushed to the left or right, the
corresponding turn signal light
will flash on and off at the same
speed as the turn signals.
High Beam
When the ignition is switched
on and the headlight dimmer
switch is set to 'high beam', the
high beam warning light will illuminate.
Low Fuel
The low fuel indicator will
illuminate when there are
approximately 1.05 US gal (4.0
liters) of fuel remaining in the
tank.
Neutral
The neutral warning light
indicates when the transmission
is in neutral (no gear selected).
The warning light will illuminate when the
transmission is in neutral with the ignition
switch in the ON position.
Low Oil Pressure Warning Light
With the engine running, if the
engine oil pressure becomes
dangerously low, the low oil
pressure warning light in the tachometer will
illuminate.
The low oil pressure warning light in the
tachometer will illuminate if the ignition is
switched on without running the engine.
High Coolant Temperature Warning
Light
With the engine running, if the
engine coolant temperature
becomes dangerously high, the
high coolant temperature
warning light in the tachometer will
illuminate.
The high coolant temperature warning light
in the tachometer will illuminate if the ignition
is switched on without running the engine.
Caution
Stop the engine immediately if the low oil
pressure warning light illuminates. Do not
restart the engine until the fault has been
rectified.
Severe engine damage will result from
running the engine when the low oil
pressure warning light is illuminated.
Caution
Stop the engine immediately if the high
coolant temperature warning light
illuminates. Do not restart the engine until
the fault has been rectified.
Severe engine damage will result from
running the engine when the high coolant
temperature warning light is illuminated.

Triumph Sprint GT Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Fuel Tank Capacity	20 litres
Max Power	130 PS (95.6 kW) @ 9, 200 rpm
Max Torque	108 Nm @ 6, 300 rpm
Exhaust	Stainless steel 3 into 1
Frame	Aluminium beam
Front Suspension	43mm
Rear Suspension	Monoshock with adjustable preload and rebound damping
Front Brakes	Twin 320 mm floating discs, Nissin 4-piston calipers
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper
Seat Height	815mm
Ignition	Digital inductive type
Swingarm	Single-sided, aluminium alloy
Wheelbase	1, 537 mm
